Description
]Key features
- 1-Chip DLP™ laser projector, 5,200lm brightness
- 4K (3840 x 2160) output resolution, ideal for museum exhibitions, education, and
- corporate offices
- 2.0x zoom lens and wide V/H Lens Shift (V: +71 %, -48 %, H: +34 %, -27 %)
- Preactivated upgrade kit for Geometry Manager Pro
- Supports 240Hz/1080p high frame rate with minimal input-to-output latency
Smooth and Detailed 4K Image Quality
Quad Pixel Drive creates sharp, detailed 4K images with Rich Color Enhancer achieving vivid, accurate color. High-speed processing supports 240 Hz/1080p frame rates with latency of 8 ms or less4 for smooth, grid-less images.
Flexible, Simple to Use, and Easy to Integrate
V/H Lens-Shift and 2.0x zoom enhance installation flexibility while two CEC-compatible HDMI® inputs and DIGITAL LINK integrate into 4K infrastructure. Free Grid simplifies operation of Geometric Adjustment functions using only the projector remote control.
Highly Reliable Low- Maintenance Projection
Filterless heat-pipe-based cooling and hermetically sealed optical block support 20,000-hour5 maintenance-free projection. Optional Early Warning Functions6 streamline management and enhance reliability in museums, classrooms, and offices.
Full specification
| Projector type | 1-Chip DLPTM projector |
|---|---|
| Display method | DLPTM chip x 1, DLPTM projection system |
| Display Device -> Panel size | 16.5 mm (0.65 in) diagonal (16:9 aspect ratio) |
| Display Device -> Number of pixels | 1920 x 1080 pixels(If a signal other than 120 Hz/240 Hz is input, it cannot be displayed at this resolution.) |
| Light source | Laser diodes |
| Light output *1 | 5,200 lm |
| Light output (ANSI) | 5,200 lm |
| Light output (Center) *1 *2 | 5,400 lm (Center) |
| Time until light output declines to 50 % -> NORMAL *3 | 20,000 hours [NORMAL] |
| Time until light output declines to 50 % -> ECO *3 | 24,000 hours [ECO] |
| Time until light output declines to 50 % -> QUIET *6 | 20,000 hours [QUIET] |
| Resolution | 4K (3840 x 2160 pixels) (With Quad Pixel Drive) |
| Contrast Ratio (typ.) *1 | 20,000:1 (Full On/Full Off)(When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1]. HDMI signal input) |
| Screen size (diagonal) | 1.02–7.62 m (40–300 in), 16:9 aspect ratio |
| Center-to-corner zone ratio *1 | 90% |
| Lens | 2.0x manual zoom (throw ratio: 1.46–2.93:1), manual focus, F 2.0–3.4, f 21.5–43.0 mm |
| Lens shift -> Vertical(from center of screen) *4 | +71 %, -48 % (manual) |
| Lens shift -> Horizontal(from center of screen) *4 | +34 %, -27 % (manual) |
| Keystone correction range | Vertical: ±40 °, Horizontal: ±20 ° |
| Installation | Ceiling/floor, front/rear, free 360-degree installation |
| Terminals -> HDMI™ IN | HDMITM 19-pin x 2 (Compatible with HDCP 2.3, Deep Color, 4K/60p signal input*6), CEC supported |
| Terminals -> COMPUTER IN(D-SUB 15pin) | D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
| Terminals -> COMPUTER OUT(D-SUB 15pin) | D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
| Terminals -> AUDIO IN(M3 Stereo Mini Jack) | M3 stereo mini-jack x 2 |
| Terminals -> AUDIO OUT(M3 Stereo Mini Jack) | M3 stereo mini-jack x 2 |
| Terminals -> SERIAL IN | D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals -> DIGITAL LINK IN / LAN | RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseTTM compliant), 100Base-TX (Compatible with PJLinkTM [Class 2], Art-Net, HDCP 2.3, Deep Color, 4K/60p signal Input*7, Extron XTP®) |
| Terminals -> LAN | RJ-45 x 1 for network connection, 10Base-T, 100Base-TX (Compatible with PJLinkTM [Class 2], Art-Net) |
| Terminals -> USB TYPE A | USB connector (Type A) x 1 for optional AJ-WM50 Series Wireless Module, for USB memory, and for power supply (DC 5 V, maximum 2 A) |
| Terminals -> SLOT | IPv4, IPv6*8 |
| Protocol versions | IPv4, IPv6*9 |
| Power supply | AC 100–240 V, 50/60 Hz, AC 110 V, 60 Hz (Taiwan) |
| Maximum power consumption | 480 W (5.0–2.2 A) (500 VA) |
| On-mode power consumption(Operating mode) -> Normal | [NORMAL] 420 W |
| On-mode power consumption(Operating mode) -> Eco | [ECO] 330 W |
| On-mode power consumption(Operating mode) -> Quiet *8 | [QUIET] 330 W |
| Standby power consumption -> Normal | 15 W (Standby Mode)[NORMAL] |
| Standby power consumption -> ECO | 0.5 W (Standby Mode)[ECO] |
| Cabinet materials | Molded plastic |
| Filter | No |
| Operation noise -> Normal *1 | 35 dB [NORMAL] |
| Operation noise -> Eco *3 | 35 dB [ECO] |
| Operation noise -> Quiet *1 | 28 dB [QUIET] |
| Dimensions (W x H x D) | 498 x 168 x 492 mm (19 5/8˝ x 6 5/8˝ x 19 3/8˝ ) |
| Dimensions (W x H x D) -> Width (not including protruding parts) | 498 mm (19 5/8˝) |
| Dimensions -> Height (including protruding parts) | 168 mm (6 5/8˝) |
| Dimensions -> Depth (not including protruding parts) | 492 mm (19 3/8˝) |
| Weight [kg] *7 | Approx. 16.1 kg (35.5 lbs) |
| Operating environment -> Operating temperature *8 *9 | 0–45 °C (32–113 °F) |
| Operating Environment -> Operating humidity (No condensation) | 10–80 % (no condensation) |
| Applicable software | Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Projector Network Setup Software |
| Control function via LAN | Crestron ConnectedTM V2, Crestron XiO CloudTM*12, Art-Net DMX, AMX® DD, and PJLinkTM (Class 2) |
| Footnote Description |
|
| Body Colour | Black/White |
| NFC | https://docs.connect.panasonic.com/projector/products/smartpjcontrol/regional.html#regional |
