The AMP205D is a compact, highly efficient Class-D amplifier integrated with Dante™ network audio. Designed for commercial AV installations, it extracts digital audio over a Dante network and outputs to passive loudspeakers. Its PoE++ support allows for flexible powering via a network switch or external 24V PSU (included).
Ideal for:
-
Corporate AV installations
-
Classrooms & meeting rooms
-
Hotel & hospitality audio zones
-
Multi-room AV systems
-
Anywhere requiring decentralized Dante-enabled amplification
⭐ Key Features
-
✅ Dante™ Audio-over-IP (2-channel RX) – AES67 & Dante Domain Manager compatible
-
✅ 2 × 50W Class-D output @ 4 Ohms (up to 100W mono in HPM)
-
✅ Supports PoE++ (2x30W @ 4Ω) or external PSU (full power)
-
✅ Compact form factor: 1/3 rack size (222mm depth)
-
✅ Auto standby and remote control (volume/standby) via GPIO
-
✅ Balanced line outputs + speaker terminals
-
✅ Passive cooling (silent operation)
-
✅ Mounting hardware included (install behind screens, above ceilings)
-
✅ Optional rack tray for combining multiple TICA® series units
📊 Specifications
🎧 Audio Inputs
-
Digital Input: Dante (2-channel)
-
Connector: RJ45, 100BASE-T Ethernet
-
Latency: Minimum 1 ms
-
Sample Rate: 48 kHz
-
Bit Depth: 24/32-bit
-
AES67 & Dante Domain Manager compatible
🔈 Amplifier Output
-
Type: Class-D
-
Modes: Stereo (ST), Parallel (PAR), High Power Mono (HPM)
-
Power Output (External PSU):
-
2 x 50 W @ 4Ω (ST)
-
1 x 100 W @ 2Ω (HPM)
-
Power Output (PoE++):
-
2 x 30 W @ 4Ω (ST)
-
1 x 60 W @ 2Ω (HPM)
-
THD+N: < 0.05%
-
SNR: > 102 dB (A-weighted)
-
Frequency Response: 15 Hz – 20 kHz (±1 dB)
-
Protection: DC, short, overload, thermal, undervoltage
🔄 Line Outputs
🎛 Control & Connectivity
-
GPIO Control: Volume, standby (external potentiometer, switch)
-
Connections: Terminal block (audio + GPIO)
-
Cooling: Convection (silent)
⚡ Power Supply
-
Primary Option: PoE++ (IEEE 802.3bt)
-
Secondary Option: External PSU (24V DC, 3.5A included)
-
Power Connector: 2-pin terminal block or IEC
📐 Physical
-
Dimensions (W × H × D): 106 × 44 × 222 mm
-
Weight: 1.66 kg
-
Material: Steel chassis, plastic front
-
Accessories Included: Mounting plates, terminal blocks, external PSU
🟩 Ideal Applications
-
Dante-based commercial systems (e.g. Q-SYS, Symetrix, Biamp, etc.)
-
AV over IP systems needing speaker zones
-
Background music or paging systems
-
Small-format distributed speaker zones in hotels, airports, offices
If you're building a Dante audio infrastructure and need to drive passive speakers directly from the network with minimal rack space, the LDAMP205D is one of the most compact, energy-efficient, and flexible solutions available.
